EKI-2000 Series

EKI-2705LX

5-port 2.5GbE Unmanaged Industrial Ethernet Switch

  • Provides 5*2.5GbE ports with auto MDI/MDIX
  • Support 10M/100M/1000M/2.5Gbps auto negotiation
  • Support jumbo frame transmission up to 12k
  • Provide slim size, DIN-rail
  • Support redundant 12-60VDC power input
  • Dual power input and relay

Support Links:

Datasheet Download 3D Model Technical Downloads
  • 5-port 2.5GbE Unmanaged Industrial Ethernet Switch

Specifications

Ethernet Communication
Ethernet Standard
  • IEEE 802.3 , 802.3u , 802.3ab , 802.3bz
RJ-45 Port Number
  • 5
Power
Power Input (DC)
  • 12 ~ 60 VDC
Power Consumption
  • 6W
Mechanism
Dimensions (W x H x D)
  • 28 x 90 x 99 mm
Mounting
  • DIN-rail, Wall mount
Environment
Operating Temperature
  • -10 ~ 60°C (14 ~ 140°F)
Storage Temperature
  • -40 ~ 85°C (-40 ~ 185°F)
Operating Humidity
  • 10~95% (non-condensing)
Certification
Safety
  • LVD 62368-1
EMI
  • CE, FCC Class A

Features & Benefits

EKI-2705LX
Unlock 2.5G Speeds – No Cable Changes Required

Unlock 2.5G Speeds – No Cable Changes Required

The EKI-2705LX is an unmanaged industrial switch with 5 x 2.5GbE ports. It enables you to instantly upgrade your network to leverage 2.5GbE-enabled devices without requiring new network cables. Featuring an industrial-grade design that ensures high quality, stability, and efficiency, along with a plug-and-play setup, the EKI-2705LX makes it easy to create an affordable, high-speed network environment.

Protect Your Network with 6KV LAN Surge Protection

Protect Your Network with 6KV LAN Surge Protection

Shield your network from high-voltage surges. Ideal for complex electrical environments, long-distance deployments, and mission-critical scenarios, it delivers stable, secure operations while minimizing maintenance and downtime costs.

Compact Size, Industrial Strength

Compact Size, Industrial Strength

As the smallest industrial-grade 2.5G unmanaged switch, it offers unmatched flexibility for installation in compact spaces, ensuring powerful performance in any environment.

Support Wide Operating Temperatures From -10 to 60 °C

Support Wide Operating Temperatures From -10 to 60 °C

Designed for versatility, EKI-2705LX supports a wide operating temperature range from -10 to 60°C, ensuring reliable performance in harsh environments.
Support Jumbo Frame Transmission Up to 12K

Support Jumbo Frame Transmission Up to 12K

Ideal for data-heavy applications like video streaming, big data analytics, and virtualization.
Dual Power Inputs for Flexibility and Redundancy

Dual Power Inputs for Flexibility and Redundancy

Offers VDC and VAC power inputs for flexible selection and redundancy. The power alarm ensures timely alerts for enhanced system reliability.
