Industrial Tablet PC

PWS-872FL

10" Rugged Tablet with Intel® Core™ i3/i5/i7/Celeron® Processor

  • 7th generation Intel® Core™ i3/i5/i7/Celeron® processor with integrated Intel® Turbo Boost technology
  • 10.1" high-brightness WXGA and WUXGA LED display with scratch-resistant Corning® Gorilla® Glass 3 panel
  • Multi-touch PCAP touchscreen with support for gloved operation
  • Rugged design with MIL-STD-810G certification, IP65 rating, and 4-ft. drop tolerance
  • WiFi 6, 4G LTE, Bluetooth 5.2, and GPS modules with BeiDou/GLONASS support
  • Built-in front and rear cameras, 1D/2D barcode scanner, and NFC RFID reader
  • Hot-swappable battery supports up to 11 hours operation
  • Microsoft® Windows 10 IoT LTSC OS
  • Optional peripherals include vehicle docking station, desk docking station, and multiple extension modules

Certifications:

Support Links:

Datasheet Technical Downloads
  • 10" Rugged Tablet with Intel® Core™ i3/i5/i7/Celeron® Processor

Specifications

Computing System
Operating System
  • Microsoft® Windows 10 IOT LTSC (64 bit), Linux Ubuntu1604
  • Microsoft® Windows 10 IOT LTSC (64 bit), Linux Ubuntu1604
  • Microsoft® Windows 10 IOT LTSC (64 bit), Linux Ubuntu1604
Camera
Front
  • X
  • 2 megapixel CMOS sensor camera with video streaming support
  • 2 megapixel CMOS sensor camera with video streaming support
Rear
  • X
  • 8 megapixel CMOS sensor camera with LED flash and auto focus
  • 8 megapixel CMOS sensor camera with LED flash and auto focus
System
Processor
  • Intel® Celeron® 3965U, 2.2 GHz
  • Intel® Core™ i3-7100U, 2.4 GHz
  • Intel® Core™ i5-7300U, 2.6 GHz (3.5 GHz Intel® Turbo Boost)
Storage
  • 128GB
  • 128GB
  • 128GB
Data Collection
  • No
  • No
  • 2D barcode scanner
Memory
  • 8GB
  • 8GB
  • 8GB
Display
Display Type
  • 1280x800, 300nits
  • 1280x800, 300nits
  • 1920x1200, 1000nits
Resolution
  • WUXGA 1920x1200, 1000 nits
  • WUXGA 1920x1200, 1000 nits
  • WUXGA 1920x1200, 1000 nits
Wireless Communication
GNSS
  • No
  • No
  • Integrated GPS, BeiDou, GLONASS
WLAN/Bluetooth
  • WiFi6+Bluetooth5.2
  • WiFi6+Bluetooth5.2
  • WiFi6+Bluetooth5.2
Sensors
_
  • Ambient light, accelerometer (g-sensor), e-compass, gyroscope (0°, 90°, 270° screen rotation)
  • Ambient light, accelerometer (g-sensor), e-compass, gyroscope (0°, 90°, 270° screen rotation)
  • Ambient light, accelerometer (g-sensor), e-compass, gyroscope (0°, 90°, 270° screen rotation)
Environment
Operating Temperature
  • -20 ~ 50°C / -4 ~ 122°F (0 ~ 40°C / 32 ~ 104°F when charging to protect the battery)
  • -20 ~ 50°C / -4 ~ 122°F (0 ~ 40°C / 32 ~ 104°F when charging to protect the battery)
  • -20 ~ 50°C / -4 ~ 122°F (0 ~ 40°C / 32 ~ 104°F when charging to protect the battery)
Storage Temperature
  • -40 ~ 60 °C (-40 ~ 140 °F)
  • -40 ~ 60 °C (-40 ~ 140 °F)
  • -40 ~ 60 °C (-40 ~ 140 °F)
IP Rating
  • IP65
  • IP65
  • IP65
Drop Tolerance
  • Up to 4 ft.
  • Up to 4 ft.
  • 4 ft. drop onto concrete
Vibration/Shock
  • MIL-STD-810G
  • MIL-STD-810G
  • MIL-STD-810G
Certifications
  • CE/FCC/CCC/SAR/UL/CE/CB/CCC
  • CE/FCC/CCC/SAR/UL/CE/CB/CCC
  • CE/FCC/CCC/SAR/UL/CE/CB/CCC
Mechanical
Dimensions (W x H x D)
  • 280 x 18.3 x 180.1 mm (11 x 0.7 x 7.1 in)
  • 280 x 18.3 x 180.1 mm (11 x 0.7 x 7.1 in)
  • 280 x 18.3 x 180.1 mm (11 x 0.7 x 7.1 in)
Weight
  • 980 g
  • 980 g
  • 980 g
Audio
Audio Jack
  • 2 x 2W speakers, 1 x microphone
  • 2 x 2W speakers, 1 x microphone
  • 2 x 2W speakers, 1 x microphone
Power System
Battery
  • Main battery: 4S1P 14.4V 3250mAh
    Hot-swappable external battery: 4S2P 14.4V 4300mAh (supports up to 11 hours operation*)
  • Main battery: 4S1P 14.4V 3250mAh
    Hot-swappable external battery: 4S2P 14.4V 4300mAh (supports up to 11 hours operation*)
  • Main battery: 4S1P 14.4V 3250mAh
    Hot-swappable external battery: 4S2P 14.4V 4300mAh (supports up to 11 hours operation*)
Input Voltage
  • 19V ± 5%
  • 19V ± 5%
  • 19V ± 5%
