USC-360 Series

USC-360D

15.6" Ultra-slim all-in-one POS system equipped with Rockchip RK3568 quad-core Cortex™-A55

  • Supports Android 12 or Linux operating systems
  • Compatible with a wide range of periphearls for retail and hospitality applications
  • Flexible installations with various mount options, such as the dual hinge stand, pole mount, Avalo stand, and VESA mount
  • Supports both integrated and separate 2nd display installation
  • Optional extendable I/O hub linked through Type-C cable
  • Second display connected through USB Type-C cable which provides power, audio, and video

Certifications:

Support Links:

Datasheet Technical Downloads
  • 15.6" Ultra-slim all-in-one POS system equipped with Rockchip RK3568 quad-core Cortex™-A55

Specifications

Processor System
CPU
  • Rockchip RK3568 quad-core Cortex™-A55
RAM
  • 4G
Storage
  • 32GB onboard eMMC
OS
  • Android 12, Linux
I/O Interface
USB Port
  • 3 x USB-C , 2 x USB 3.0, 2 x USB 2.0
Ethernet
  • 1 x RJ45 10/100/1000 Mbps
Audio
  • 2 x 2W speaker installed. 1 x Line out
Power Supply
Input Voltage
  • 65W via power adapter
Display
Size
  • 15.6" TFT LCD
Touch Screen
Type
  • Projected Capacitive Touch Panel (Pcap. Flat Glass)
Color
Color
  • Black
Environment
Certification
  • FCC, CE, CCC, BSMI, UL, CB
Operating Temperature
  • 0~40° C
Dimensions
Dimensions
  • 381 x 230.4 x 31.5 mm
Weight (kg)
Weight (kg)
  • 4 Kg (Net); 4.5 Kg (Gross)

Accessories
